Fuel Quick Connector 7.89(5/16)-7.89-6 3ways SAE

Basic Info

Model No.: B15

Product Description


Item: Fuel Quick Connector 7.89(5/16)-7.89-6 3ways SAE

Model: B15

Media: Fuel system


Size: Ø7.89mm-3ways
Hose fitted : 7.89mm End Piece 0° and 6.0x8.0mm fir tree 90°

Material: PA66 or PA12+30%GF


Quick Connector Working Environment
1. Gasoline and diesel fuel delivery systems, ethanol and methanol delivery systems or their vapor venting or evaporating emission control systems.
2. Operating pressure: 500kPa, 5bar,(72psig)
3. Operating vacuum: -50kPa, -0.55bar,(-7.2psig)
4. Operating temperatures: -30℃ to 120℃ in continuous, short time 150℃


The Advantage of Shinyfly Quick Connector
1. Simple
• One assembly operation
Only one action to connect and secure.
• Automatic connection
The locker automatically locks when the end piece is properly seated.
• Easy to assemble and dis-assemble
With one hand in tight space.
2. SMART
• The locker's position gives an obvious confirmation of the connected state on the assembly line.
3. SECURE
• No connection until end piece is properly seated.
• No disconnection unless voluntary action.


Other Technical Data
Compliant with SAE standards
Large range of diameters
Different colors for locking spring
Various angles, geometries

Qc

Quick Connection
